6 - 9 porte

Managed 8 + 2 Ports Gigabit PoE+ Switch
4 x RJ45 ports are up to 2.5Gbps with PoE++ (95W)
4 x RJ45 ports are up to 1Gbps with PoE+ (36W)
PoE Power Budget Is 240 Watts
with PoE insulation
2 x SFP slot for 1G, 2.5G and 10Gbit SFP module
RJ45 type RS232 console interface for switch control
up to 95W to 802.3BT / POH units
Detects automatic PoE Suitable devices (PD)
IGMP Snooping
Link Aggregation
Cyper Security
PoE Up to 100 meters
Dim: 330 x 200 x 45 mm
Supply voltage: 100 - 240vac

Managed Gigabit switch 2 x RJ45, 2 x Fiber
4 x RJ45 10/100/1000Mbps
2 x SFP 100/1000Mbps
Support ERPS (Ring protection)
IGMP/MLD Snooping (IPv4, IPv6)
Up to 256 VLAN groups
Support Cisco ether-channel (Static Trunk)
Port mirroring - up to 4 sessions
Supply voltage: 9 - 48VDC, 24VAC
Size: 135 x 88 x 32 mm
Temperature: -40 to +75°C
DIN-mounting

4 x 10/100/1G/2.5GBASE-T RJ45 copper ports
2 x 10GBASE-SR/LR SFP+ slots, compatible with 1G/2.5GBASE-X SFP
1 x RJ45-to-RS232 console interface for basic management and setup
DC 9 to 48V input or AC 24V input
DIN-rail and wall-mountable designs
IP30 aluminum case
Temperature -40 to +75 degrees C
2 x digital input (DI)
2 x digital output (DO)
Integrates sensors into auto alarm system
Transfers alarm to IP network via email and SNMP trap
IPv4 dynamic routing protocol supports RIPv2 and OSPFv2
IPv6 dynamic routing protocol supports OSPFv3
IPv4/IPv6 hardware static routing
Supports G.8032 ERPS (Ethernet Ring Protection Switching)
IEEE 1588v2 PTP (Precision Time Protocol) transparent clock mode
Supports IPv4 IGMP snooping v1, v2 and v3
Supports IPv6 MLD snooping v1 and v2
Switch Management Interfaces
SNMP Management

8-port 10/100/1000BASE-T Gigabit Ethernet switch.
Plug-and-play operation without software installation.
VLAN isolation to prevent multicast or broadcast storms.
16 Gbps bandwidth and 9K jumbo frame support.
Features IEEE 802.3az energy efficient Ethernet standards.
Silent, compact and durable design.
Dimensions: 168 x 93 x 32 mm.
Power supply: 100-240V AC, 50/60 Hz, 0.2A

5-Port 10/100/1000BASE-T Gigabit Ethernet Switch
Plug-and-play operation without software installation.
VLAN isolation to prevent multicast or broadcast storms.
10 Gbps bandwidth and 9K jumbo frame support.
Features IEEE 802.3az energy efficient Ethernet standards.
Silent, compact and durable design.
Dimensions: 155 x 86 x 26 mm
Power supply: 5V DC, 1A

8 + 2 port PoE switch for DIN mounting
Un-managed
8 x 10/100/1000Mbit - RJ45 with auto MDI/MDI-X
PoE+ (30W) - power budget is 240 Watt
2 x SFP slot 100/1000Mbit fiber port
IP30 metal housing
DIN rail
Redundant Power input
48-54VDC / 7A, redundant, with polarity protection
Standard/extend switch 100/250 meter cable
6000VDC Ethernet ESD protection
Extended temperature -40 to 75°C
IEEE 802.3at
Dimensions: 152 x 106 x 66 mm
