Extender / Amplifier

4K HDMI Extender over the patch cable
PoC (Power Over Cable) - Power supply to be one party TX or RX
2.0b HDMI / HDCP 2.2 / 1.4
up to 120 meters
4096 x 2160 @ 60Hz (120m), 1920 x 1080 @ 60 Hz (150m)
4K @ 50 / 60Hz 4:4:4
1080p @ 120Hz
Remote-IR in both directions
TX: HDMI in, HDMI out, IR Input + out (3.5mm jack), DC in, RJ45, RS232
RX: HDMI out, audio out, IR Input + out (3.5mm jack), RJ45, RS232
Plug and Play
Power supply: 24V 1A (1 pc included)
Dimensions: 157 x 90 x 20 mm | Weight: 333g
Operating temperature: 0 - + 40 ° C
Humidity: 20 - 90% RH (no condensation)

HDMI Matrix over IP.
Video Wall configuration
Setup with DIP switches (TX-RX Pair)
Max 24 transmitters and 96 receivers (contact us for buying TX or RX units separately.) < br> HDMI 1.3, HDCP 1.3.
HDMI loop out to the local monitor
Resolution 1080p @ 60/50/30/25 / 24Hz, 720p @ 60 / 50Hz.
point to point over Cat 6. Maximum . 100meter. Point to many Hotels can be supplied via PoE (802.3af) or 12VDC 1A (PSU included).
Power Consumption: 2.5W.
Switch must support protocol: IGMP Snooping or IFMP.
Delay: 120ms
Operating temperature: 0 ~ 40 ° C.

VGA Extender over TCP / IP or Point to Point.
Up to 200 meters over CAT 5e / 6 patch cable.
1920 x 1080 @ 60Hz
3.5mm Audio
USB for keyboard and mouse only!
Audio frequency: 32kHz, 44.1kHz, 48kHz
Sound format: DTS-HD / Dolby true HD / LPCM7.1 / DTS / DSD
Operating temperature: -5 ~ 70 ° C
Dimensions: 104 x 92 5 x 24 mm

High End DisplayPort Extender
Resolution Up to UHD 4K, 3840 x 2160 @ 30Hz
single cable, CAT 6A up to 100 m
point-to-point connection
Plug and Play; No software drivers required
with Edid
supply voltage: 12VDC - Both TX and RX
can power the other device over the patch cable
Dim: 102 x 66 x 30 mm

HDMI sends and receives over RJ45 Cat. 6/6e
1080P@60Hz
HDMI 1.3, HDCP 1.2
EDID
Suitable for transferring HDMI over an existing RJ45 installation
Up to 50 meters (Depends on cable quality)
Use only quality cable
HDMI male, RJ45 female
POWER over cable, the supply to the reciver module is transferred via cable.
Can be supplied with 5vDc via Micro USB Power on each module

KVM receiver to create several operating positions for one PC sends
KVM Extender up to 150 meters point to point Cat 6 cable
KVM Extender over TCP / IP.
A BOOST HDMI150-D LO transmitter supports up to 253 recipients
up to 1920 x 1080p @ 60Hz
Audio Format: DTS-HD / Dolby true HD / LPCM7.1 / DTS / DSD
USB KVM feature: Keyboard and mouse (HID signal) remote
USB 2.0 up to 480Mbps
Over router / switch with IGMP snooping
H.264 video.komprimering
Video standard: HDMI 1.3 and HDCP 1.2 standard
EDID emulation via PC's graphics card

Emulate the monitor's EDID information
Max 2560 x 1600 @ 60hz

Transmits uncompressed HD video and audio over CAT6a / 7 cable up to 100 meters
Can be powered monitors or receivers with hdbaset with PSE
PSE is the equipment that sends PoE out on RJ45 port
Power from mini-USB with no PSE connected
Map HDMI cable, eliminating the need for extra cables
Resolution up to UHD (3840 x 2160), Deep Color and HD Audio formats
4K @ 60Hz 4: 2 : 0
4K @ 30Hz 4: 4: 4
HDCP compliant and Blu-ray ready
Plug and Play no software installation
Compact size.
Easy to install
REQUIRE THE BEST QUALITY CABLE! No support if the cord is from Danbit

Receives HDMI video signal via Cat.6A cable up to 100 meters
Resolution: 4K @ 60Hz 4: 2: 0)
Resolution: 4K @ 30Hz 4: 4: 4
Full HD (1920 x 1080)
User hdbaset technology
PoE (POH) - only a power supply of the receiver unit.
HDCP compliant and ready for Blu-ray
Supports IR remote
automatic power saving function (can selectable)
Plug and Play, no software installation
Powered by 48VDC
Dimensions: 140 x 85 x 34 mm
REQUIRE THE BEST QUALITY CABLE! No support if the cord is not from Danbit

DisplayPort (DP) Cable
Perfect picture quality
Ultra Resolution 8K at 60Hz, 4K@144 MHz
Plug and Play
Direction source to display
32.4Gbps Bandwidth
POC - Remote unit Power supplied in cable
Non isolated

DisplayPort (DP) Cable
perfect alternative to HDMI Extender
Ultra solution 8K, 60Hz
AOC (Active Optical Cable) to 4-core optical fiber
Plug and Play
HDR RGB 4: 4: 4 (high Dynamic Range)
32.4Gbps bandwidth up to 100m
Supports 3D visual effects
Cable thickness: 5mm
100 meter
black
24K Gold plated
Non isolated

DisplayPort (DP) Cable
perfect alternative to HDMI Extender
Ultra solution 8K, 60Hz
AOC (Active Optical Cable) to 4-core optical fiber
Plug and Play
HDR RGB 4: 4: 4 (high Dynamic Range)
32.4Gbps bandwidth up to 100m
Supports 3D visual effects
Cable thickness: 5mm
70 meter
black
24K Gold plated
Non isolated

DisplayPort (DP) Cable
perfect alternative to HDMI Extender
Ultra solution 8K, 60Hz
AOC (Active Optical Cable) to 4-core optical fiber
Plug and Play
HDR RGB 4: 4: 4 (high Dynamic Range)
32.4Gbps bandwidth up to 100m
Supports 3D visual effects
Cable thickness: 5mm
50 meter
black
24K Gold plated
Non isolated

DisplayPort (DP) Cable
perfect alternative to HDMI Extender
Ultra solution 8K, 60Hz
AOC (Active Optical Cable) to 4-core optical fiber
Plug and Play
HDR RGB 4: 4: 4 (high Dynamic Range)
32.4Gbps bandwidth up to 100m
Supports 3D visual effects
Cable thickness: 5mm
20 meter
black | 24K Gold plated
Non isolated

DisplayPort (DP) Cable
perfect alternative to HDMI Extender
Ultra solution 8K, 60Hz
AOC (Active Optical Cable)
4-core optical fiber
Plug and Play
HDR RGB 4: 4: 4 (high Dynamic Range)
32.4Gbps bandwidth up to 100m
Supports 3D visual effects
Cable thickness: 5mm
8 meter
black
24K Gold plated
Non isolated

4K HDMI Extender Over Patch Cable
HDMI 1.4 / HDCP 1.2
Up to 120 meters
4K @ 30 Hz
One-to-One or One-To-Many
Max 12 RX Can be connected one TX (Daisy Chain)
120m Cat 6 / 100m Cat 5e
remote control IR from RX to TX
Plug and Play
Power supply: 5V 1A to USB port (2 pcs supplied)
Dimensions: 100 x 85 x 25 mm
Operating temperature: -15 - + 55 ° C
Extra receivers can be purchased BOOST-HDMI120-4K30RX

4K HDMI Extender Over IP
HDMI 1.4 / HDCP 1.4
Up to 120 meters (point-to-points)
4K @ 30 Hz
2 x USB-A 2.0 (HID emulation)
One-to-One or One-To-Many
Max 32 RX Can be connected One TX (Via Ethernet Switch)
Remote-IR from TX to RX
Plug and Play
Power Supply: 5V 1A (2 included)
Dimensions: 107 x 105 x 27 mm
Operating temperature: -15 - + 55 ° C
Weight: TX 499G, RX 494G
acquisition: K-USB4AM-AM -Fe to connect the USB-A port to PC

KVM extender for VGA, USB K/M over Cat 5/5e/6 UTP
Up to 300 meters distance from a computer
1920 x 1440 @ 60Hz
2 users can share 1 computer, locally and remotely
Ideal for professional video applications
Only supports the standard USB HID keys
USB ONLY for keyboard and mouse (not touch)
No drivers needed or software required
Rotary knob adjustment of brightness and contrast (color)
Dimensions: 95 x 97 x 28mm
Supply voltage: 9~12VDC, PSU included

DisplayPort KVM extender, 4K@60Hz and HD
100 - 150 meters with cat. 6a patch cable (need good quality cable!)
Up to 100 meters with 4K@50Hz
4 x USB 2.0 ports on the remote module
1 x USB B on local module
Transparent USB for K/M, USB drive, HDD etc.
2-way audio transmission - 3.5 mm Jack
DP1.2, HDCP1.3, USB2.0 compatible and Blu-Ray
Point-to-point cable connection
HDBaseT 2.0: Good EMI immunity
Supply voltage: 12VDC / 1.5A PSUs included
Consumption: 10W
Dimensions: 125 x 123 x 32 mm
Operating temperature: 0 - + 45°C

Resolution up to 1080p@60Hz.
HDMI distribution up to 70M.
No external power is required for the RX unit.
Built-in HDMI loop out port on TX unit for an additional HDMI monitor.
Stackable to another TX for 1 in 8/12 out.
Supports RS232, CEC, EDID.
Supports RS232 control.
