Antaira netværksprodukter

Supporter 6-Port 10/100Tx and
2 x Gigabit Combo Ports
2 x 10/100/1000Tx RJ45
2 x 100/1000 SFP Slots
Supporter Auto MDI/MDI-X Funktion
Store-and-Forward Switching Architecture
8K MAC Address Table
Surge Protection: 2,000 VDC Support
ESD Protection: 6,000 VDC Support
UL Class I, Division 2 Certified
Redundant Power Input Design: 12~48VDC
Indbygget 1 x Relay Output til Power Failure advarsel
IP30 Rugged Metal
Væg og DIN skinne montering
Driftstemperatur EOT: -40° to 75° C

Supporter 8-Port 10/100Tx
2 Gigabit Combo Ports
6 x RJ45 Porte 10/100Tx
2 x 10/100/100 RJ45
2 x 100/1000 SFP Slots
Supporter Auto MDI/MDI-X
Non-Blocking Switching Fabric
8K MAC Address
Surge Protection: 2,000 VDC
ESD Protection: 6,000 VDC
UL Class I, Division 2 Certified
Redundant Power Input Design: 12~48VDC
1 x indbygget relæ Output til Power Failure advarsel
IP30 Rugged Metal Case Design
DIN-skinne og væg montering
Driftstemperatur STD: -10° to 70°C

Supporter 8-Port 10/100Tx
2 Gigabit Combo Ports
6 x RJ45 Porte 10/100Tx
2 x 10/100/100 RJ45
2 x 100/1000 SFP Slots
Supporter Auto MDI/MDI-X
Non-Blocking Switching Fabric
8K MAC Address
Surge Protection: 2,000 VDC
ESD Protection: 6,000 VDC
UL Class I, Division 2 Certified
Redundant Power Input Design: 12~48VDC
1 x indbygget relæ Output til Power Failure advarsel
IP30 Rugged Metal Case Design
DIN-skinne og væg montering
Driftstemperatur EOT: -40° to 75°C

5 x 10/100Tx RJ45 hurtig Ethernet
M12 (D-coded hun) Connector IP67 beskyttet
IP67 Plastic Case Design
RJ45 Port Support Auto MDI / MDI-X
Auto Negotiation hastighed, Half / Full Duplex
Store-and-Forward Switching Architecture
Forsyningsspænding: 12~48VDC
Power Polarity Reverse Protection
Overload Current Protection
DIN-Skinne eller væg montering
Dimensioner: 37.13 x 215.73 x 32.8 mm (W x H x D)
Driftstemperatur: STD: -10°C to 70°C

5 x 10/100Tx RJ45 hurtig Ethernet
M12 (D-coded hun) Connector IP67 beskyttet
IP67 Plastic Case Design
RJ45 Port Support Auto MDI / MDI-X
Auto Negotiation hastighed, Half / Full Duplex
Store-and-Forward Switching Architecture
Strømforsyning: 12~48VDC
Power Polarity Reverse Protection
Overload Current Protection
DIN-Skinne eller væg montering
Dimensioner: 37.13 x 215.73 x 32.8 mm (W x H x D)
Driftstemperatur: EOT: -40°C to 75°C

8 x 10/100/1000Base-T(X) RJ45
PoE (P.S.E.) Porte
IEEE 802.3at
Op til 30 Watt pr. Port
9.6Kbytes Jumbo Frame
Forsyningsspænding, dual wide range 12 ~ 36VDC
Auto-Negotiation & Auto-MDI/MDI-X
Store-and-Forward Transmission
Flow Control
IP-30 Housing Design
DIN-Skinne og væg montering
UL Class I, Division 2 Certified

8 x 10/100/1000Tx RJ45
PoE+ (30W / port) IEEE 802.3at
2 x 100/1000 SFP porte
Auto MDI/MDI-X Funktion
Store-and-Forward Switching Architecture
20Gbps Back-Plane (Switching Fabric)
8K MAC Address Table
9.6Kbytes Jumbo Frame
Surge Protection: 2,000 VDC
ESD Protection: 6,000 VDC
UL Class I, Division 2 Certified
Forsyningsspænding: 48~55VDC
Indbygget relæ Output for Power Failure
IP30 Rugged Metal Case Design
DIN-Skinne og Væg montering
Driftstemperatur: -40° to 75°C

8 x 10/100/1000Tx RJ45
PoE+ (30W/port)IEEE 802.3at PoE
2 x 100/1000 SFP porte
Auto MDI/MDI-X Funktion
Store-and-Forward Switching Architecture
20Gbps Back-Plane (Switching Fabric)
8K MAC Address Table
9.6Kbytes Jumbo Frame
Surge Protection: 2,000 VDC
ESD Protection: 6,000 VDC
UL Class I, Division 2 Certified
Forsyningsspænding: 48~55VDC
Indbygget relæ Output for Power Failure
IP30 Rugged Metal Case Design
DIN-Skinne og Væg montering
Driftstemperatur STD:-10° til70°C

8 x 10/100/1000Tx RJ45 (30W/port)
2 x 10/100/1000Tx RJ45
2 x 100/1000 SFP porte
Auto MDI/MDI-X Funktion
Store-and-Forward Switching Architecture
24Gbps Back-Plane (Switching Fabric)
8K MAC Address Table
9.6Kbytes Jumbo Frame
Surge Protection: 2,000 VDC
ESD Protection: 6,000 VDC
UL Class I, Division 2 Certified
Strømforsyning: 48~55VDC
Indbygget relæ Output til Power Failure
IP30 Rugged Metal Case Design
DIN-Skinne og Væg montering
Driftstemperatur STD: -10° to 70° C

8 x 10/100/1000Tx RJ45 (30W/port)
2 x 10/100/1000Tx RJ45
2 x 100/1000 SFP porte
Auto MDI/MDI-X Funktion
Store-and-Forward Switching Architecture
24Gbps Back-Plane (Switching Fabric)
8K MAC Address Table
9.6Kbytes Jumbo Frame
Surge Protection: 2,000 VDC
ESD Protection: 6,000 VDC
UL Class I, Division 2 Certified
Strømforsyning: 48~55VDC
Indbygget relæ Output til Power Failure
IP30 Rugged Metal Case Design
DIN-Skinne og Væg montering
Driftstemperatur STD: -40° to 75°C

8 x 10/100/1000Tx RJ45 (30W/port)
4 x 100/1000 SFP porte
Auto MDI/MDI-X Funktion
Store-and-Forward Switching Architecture
24Gbps Back-Plane (Switching Fabric)
8K MAC Address Table
9.6Kbytes Jumbo Frame
Surge Protection: 2,000 VDC
ESD Protection: 6,000 VDC
Forsyningsspænding: 48~55VDC
Indbygget relæ Output til Power Failure
IP30 Rugged Metal Case Design
DIN-Skinne og Væg montering
Driftstemperatur: -10° to 70° C

8 x 10/100/1000Tx RJ45
PoE+ (30W / port)
4 x 100/1000 SFP porte
Auto MDI/MDI-X Funktion
Store-and-Forward Switching Architecture
24Gbps Back-Plane (Switching Fabric)
8K MAC Address Table
9.6Kbytes Jumbo Frame
Surge Protection: 2,000 VDC
ESD Protection: 6,000 VDC
Forsyningsspænding: 48~55VDC
Indbygget relæ Output til Power Failure
IP30 Rugged Metal Case Design
DIN-Skinne og Væg montering
Driftstemperatur: -40° to 75° C

12 x 10/100/1000Tx RJ45 (30W/port) IEEE 802.3at PoE+
4 x 100/1000 SFP porte
Store-and-Forward Switching Architecture
8K MAC Address Table
12.2Kbytes Jumbo Frame
Surge Protection: 2,000 VDC
ESD Protection: 6,000 VDC
Strømforsyning: 48~55VDC
Indbygget relæ Output til Power Failure
IP30 Rugged Metal Case Design
DIN-Skinne og Væg montering
Driftstemperatur STD: -10° to 70° C

12 x 10/100/1000Tx RJ45
PoE+ (30W / port) IEEE 802.3at
4 x 100/1000 SFP porte
Store-and-Forward Switching Architecture
8K MAC Address Table
12.2Kbytes Jumbo Frame
Surge Protection: 2,000 VDC
ESD Protection: 6,000 VDC
Forsyningsspænding: 48~55VDC
Indbygget relæ Output til Power Failure
IP30 Rugged Metal Case Design
DIN-Skinne og Væg montering
Driftstemperatur: -40° to 75°C

24 x 10/100/1000Tx RJ45 (30W/port) IEEE 802.3at PoE+
2 x Gigabit combo (2 x RJ45, 2 x FTP)
Auto MDI/MDI-X Function
Store-and-Forward Switching Architecture
8K MAC Address Table
9.6Kbytes Jumbo Frame
Surge Protection: 2,000 VDC
ESD Protection: 6,000 VDC
Strømforsyning: 48~55VDC
Indbygget relæ Output til Power Failure
1U 19" Rackmount design
Driftstemperatur STD: -10° to 70° C

24 x 10/100/1000Tx RJ45 (30W/port) IEEE 802.3at PoE+
2 x Gigabit combo (2 x RJ45, 2 x FTP)
Auto MDI/MDI-X Function
Store-and-Forward Switching Architecture
8K MAC Address Table
9.6Kbytes Jumbo Frame
Surge Protection: 2,000 VDC
ESD Protection: 6,000 VDC
Strømforsyning: 48~55VDC
Indbygget relæ Output til Power Failure
1U 19" Rackmount design
Driftstemperatur STD: 40° to 75° C

8 x porte 10/100/1000Tx, IEEE 802.3at Compliant PoE+
Redundant forsyningsspænding: 24 - 55VDC
Indbygget Power Booster Design for PoE/PoE+
Indbygget relæ output - advarsel for Power/PoE Failure
Bypass Design for Daisy Chain Redundans
Digital Input/Digital Output
IP67 Rugged vandtæt Metal design
M12 X-Coded forbindelse for at sikre tæt og robust forbindelse
Væg montering
Driftstemperatur:-10° to 60°C
Dimensioner:253.57 x 122 x 116.12 mm (W x H x D)

1000Mbit Multi Mode Mediekonverter til RJ45
1 x RJ45 10/100/1000BaseT
1 x 1000BaseSX/LX med SC stik Multi Mode
Back-Pressure in Half-Duplex
Auto MDI/MDI-X function
Store-and-Forward mechanism
Op til 220m / 550m
Dimensioner: 97 x 70 x 26 mm
Driftstemperatur: 0 - +50°C
Strømforsyning: 5VDC/2A medfølger

Gigabit WDM medieonverter til single core fiber med SC stik
WDM-B - TX 1550nm / RX 1310nm
(skal kommunikere med WDM-A i anden ende af fiberen!)
IEEE 802.3/u/ab 10/100/1000BaseT
IEEE 802.3z 1000BaseX
Jumbo Frame (9K bytes)
Store-and-Forward Switching Mechanism
Auto-Crossover for MDI/MDIX in TP Port
Auto-Negotiation in TP Port
Flow Control
Link Alarm
Auto & Force Mode Configuration
Dimensioner:71 x 94 x 26 mm
5VDC/1.5A strømforsyning medfølger
Tilkøb: DIN beslag

24 x 10/100/1000Tx RJ45
2 x Gigabit Combo Porte
2 x 10/100/1000Tx RJ45
2 x 100/1000 SFP Slots
Auto MDI/MDI-X Function
Store-and-Forward Switching Architecture
8K MAC Address Table
9.6Kbytes Jumbo Frame
Surge Protection: 2,000 VDC
ESD Protection: 6,000 VDC
Redundant Power Input Design: 90~264VAC
1 x indbygget Relæ Output til Power Failure
IP40 Rugged Metal Case Design
1U 19" Rackmount design Support
Driftstemperatur: -10° to 70° C
